PHP-GLFW: An OpenGL and GLFW Extension for PHP¶
A fully-featured OpenGL and GLFW extension for PHP. Batteries included π!
PHP-GLFW allows you to create 2D and 3D real-time applications in PHP. Bringing a whole different set of tools into the PHP world to develop graphical applications like games, scientific simulations, user interfaces, and more.
-
Install in 5 minutes
If you haven't installed PHP-GLFW yet, follow the installation guide for your platform.
-
PHP OpenGL Tutorial
Everything ready to get started? Jump right into the first chapter of the tutorial.
-
API Docs
Checkout the API documentation for all the functions and classes available in PHP-GLFW.
-
Examples
Want to directly dig into example code? Check out the examples folder.
What is this extension? Features π¶
PHP-GLFW aims to be one extension containing all basics you need to start building graphical applications in PHP. That means that PHP-GLFW does NOT only provide GLFW library bindings. Instead, it also includes OpenGL bindings and a bunch of classes and helpers pretty much required for building these types of applications.
OpenGL¶
- Full native support of OpenGL (4.1+ core), GPU accelerated rendering in PHP.
- Targeting OpenGL 4.1, but it can also be built for newer versions.
- Support for OpenGL extensions (limited).
- Mostly mirroring the C API, adjustments were made where required or otherwise nonsensical.
- We currently support about ~90% of the full standard, check GLSUPPORT.md
GLFW¶
This extension comes obviously with bindings for the amazing GLFW library. GLFW comes with great features, to name a few:
- Multiplatform window creation and handling (macOS, Windows, Linux)
- Support for multiple windows and monitors
- Real-time user input handling
- Keyboard and Mouse event handling
- Joystick input support
PHPGL - Math¶
PHPGL is what I call the extras in this extension, aka classes and helpers additionally provided that are pretty much a requirement for these kinds of applications. PHP-GLFW comes with a mathematics library written in C, covering the most common operations required for graphical applications.
- Supported structs:
Vec2
,Vec3
,Vec4
,Mat4
, andQuat
- Includes most common matrix operations for the use case like:
lookAt
,perspective
,inverse
,rotate
, etc.
Having this integrated into the extension comes with a bunch of advantages:
- It's fast
- Low memory footprint
- The math structures have overloaded operators, so you can write things like:
-
Some OpenGL functions can directly accept the math structs as arguments
PHPGL - Buffers¶
This extension also contains a collection of buffer objects that internally hold data in native types.
- Can handle large arrays of data
- Low memory footprint and very fast
-
Data is stored internally to be directly uploadable to the GPU
PHPGL - Textures¶
PHP-GLFW supports the loading of images/textures into buffers without requiring an additional extension:
- Can load common image formats such as
jpg
,png
,tga
,bmp
,gif
(gd or Imagick is not required) - Can write images/textures back to disk
-
Writes data into a
BufferInterface
object, giving full access to the bitmap from userland
PHPGL - Geometry¶
PHP-GLFW also comes with a .obj
Wavefront file loader. This allows you to load and parse .obj
files. We also provide a few helpers
to generate tangent and bitangent vectors for the loaded geometry directly. Currently, we only support triangulated geometry and no quads.
- Can parse
.obj
and.mtl
files - Can generate the normal, tangent, and bitangent vectors for the loaded geometry on the fly
- Allows you to extract separate meshes and groups from the loaded geometry
- Can group the vertices by their material
-
Can reindex extracted meshes to reduce the number of vertices
How are the bindings achieved?¶
Instead of porting function by function manually, PHP-GLFW parses the OpenGL specs to generate most of this C extension. Adjustments are made manually where necessary.
